Page #7 background image
= pÉêîáÅÉ=j~åì~ä=^`k=O`I=OpI=P`= m~ÖÉ=S=ENTF=
=
Position Partnumber Description Comment Side
D2 1N4004 Diode power 1N4004 Top
D3 1N4004 Diode power 1N4004 Top
D4 1N4004 Diode power 1N4004 Top
D5 LGRN2.5x5LY Diode LED Green 2.5x5mm lying Top
D6 1N4148 Diode signal 1N4148 Top
D7 1N4148 Diode signal 1N4148 Top
D8 Variant dependent, see separate list Top
D9 Variant dependent, see separate list Top
D206 1N4148 Diode signal 1N4148 Top
D207 1N4148 Diode signal 1N4148 Top
D208 Variant dependent, see separate list Top
D209 Variant dependent, see separate list Top
D500 1N4148 Diode signal 1N4148 Top
D501 15V.4W5% Diode zener 15V .4W 5% Top
D502 1N4148 Diode signal 1N4148 Top
D503 1N4148 Diode signal 1N4148 Top
D504 Variant dependent, see separate list Top
F1 TA160250-5x20 Fuse slow blow 160mA 250V 5x20mm Top
F2-115V TA315250-5x20 Fuse slow blow 315mA 250V 5x20mm Top
F2-230V TA160250-5x20 Fuse slow blow 160mA 250V 5x20mm Top
K1 NC3FA-H2_NEU Connector XLR 3pole female 90dg NEUTRIK NC3FA-H2 Top
K2 NC3MA-H_NEU Connector XLR 3pole male 90dg NEUTRIK NC3MA-H Top
K3 NC3MA-H_NEU Connector XLR 3pole male 90dg NEUTRIK NC3MA-H Top
K4 Variant dependent, see separate list Top
K201 NC3FA-H2_NEU Connector XLR 3pole female 90dg NEUTRIK NC3FA-H2 Top
K202 NC3MA-H_NEU Connector XLR 3pole male 90dg NEUTRIK NC3MA-H Top
K203 NC3MA-H_NEU Connector XLR 3pole male 90dg NEUTRIK NC3MA-H Top
K204 Variant dependent, see separate list Top
K500 TBPC3P4M2.5 Terminal block PCB 3pole 4module 2.5mm2 Top
K500B MLEU3x.752mBLK Mains lead EU Plug type CEE7/VII 3x.75mm2 2m Black Top
P1 VR10KLIN2_TOK Potentiometer 10K LIN 2step TOKOS B103 TP96N01
RY5194A
Top
P2 VR47KLY2X3M Trimpotentiometer 47K lying 2x3modules Top
P3 VR10KLIN2_TOK Potentiometer 10K LIN 2step TOKOS B103 TP96N01
RY5194A
Top
P4 VR47KLY2X3M Trimpotentiometer 47K lying 2x3modules Top
P5 Variant dependent, see separate list Top
P6 Variant dependent, see separate list Top
P201 VR10KLIN2_TOK Potentiometer 10K LIN 2step TOKOS B103 TP96N01
RY5194A
Top
P202 VR47KLY2X3M Trimpotentiometer 47K lying 2x3modules Top
P203 VR10KLIN2_TOK Potentiometer 10K LIN 2step TOKOS B103 TP96N01
RY5194A
Top
P204 VR47KLY2X3M Trimpotentiometer 47K lying 2x3modules Top
P205 Variant dependent, see separate list Top
P206 Variant dependent, see separate list Top
Q501 BC337 Transistor bipolar signal BC337 Top
Q502 BC327 Transistor bipolar signal BC327 Top
Q505 BC547B Transistor bipolar signal BC547B Top
R1 19K6.7W1% Resistor Metal Film 19K6.7W1% Top
R2 19K6.7W1% Resistor Metal Film 19K6.7W1% Top
R3 19K6.7W1% Resistor Metal Film 19K6.7W1% Top
R4 19K6.7W1% Resistor Metal Film 19K6.7W1% Top
R5 100K.7W1% Resistor Metal Film 100K.7W1% Top
R6 - Not used Top
R7 34K.7W1% Resistor Metal Film 34K.7W1% Top

Other manuals for Lab.gruppen ACN 2C

Preview: Specifications
Specifications1 page

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Lab.gruppen ACN 2C and is the answer not in the manual?

Lab.gruppen ACN 2C Specifications

ACN 2C

Filters IconFilters
filter type4-pole, state variable
slope24 dB/octave
subsonic speaker protectionHigh-pass Filter at 40 Hz and 18 dB/octave
Crossover Frequencies IconCrossover Frequencies
crossover frequencies80, 160, 250, 330, 400, 500, 600, 660, 800, 840, 950, 1000, 1100, 1200, 1300 and 1400 Hz
Input IconInput
max input level20 dBu
input impedance20 kohms
Output IconOutput
max output level20 dBu in 5 kohms
gainadjustable ±8 dBu
max output level in 600 ohms17 dBu
Distortion and Dynamic Range IconDistortion and Dynamic Range
TDH at 0 dBu0.02% typically
dynamic range110 dB
Power Supply IconPower Supply
power supply voltage220 V - 110 V
power supply frequency50-60 Hz
Overall Dimensions IconOverall Dimensions
width483 mm (19")
height44 mm (1¾")
depth135 mm (5.3")

ACN 2S

Filters IconFilters
filter type4-pole, state variable
slope24 dB/octave
subsonic speaker protectionHigh-pass Filter at 40 Hz and 18 dB/octave
Crossover Frequencies IconCrossover Frequencies
crossover frequencies40, 50, 60, 65, 75, 82, 90, 100, 110, 115, 125, 135, 140, 150, 160 and 165 Hz
Input IconInput
max input level20 dBu
input impedance20 kohms
Output IconOutput
max output level20 dBu in 5 kohms
gainadjustable ±8 dBu
max output level in 600 ohms17 dBu
Distortion and Dynamic Range IconDistortion and Dynamic Range
TDH at 0 dBu0.02% typically
dynamic range110 dB
Power Supply IconPower Supply
power supply voltage220 V - 110 V
power supply frequency50-60 Hz
Overall Dimensions IconOverall Dimensions
width483 mm (19")
height44 mm (1¾")
depth135 mm (5.3")

ACN 3C

Filters IconFilters
filter type4-pole, state variable
slope24 dB/octave
subsonic speaker protectionHigh-pass Filter at 40 Hz and 18 dB/octave
Crossover Frequencies IconCrossover Frequencies
crossover frequencies lo-mid80, 125, 170, 200, 250, 300, 350, 400, 440, 480, 530, 580, 620, 660, 700, and 7 Hz
crossover frequencies mid-hi500, 800, 1000, 1300, 1600, 2000, 2300, 2500, 2800, 3000, 3300, 3700, 4000, 4300, 4600 and 4800 Hz
Input IconInput
max input level20 dBu
input impedance20 kohms
Output IconOutput
max output level20 dBu in 5 kohms
gainadjustable ±8 dBu
max output level in 600 ohms17 dBu
Distortion and Dynamic Range IconDistortion and Dynamic Range
TDH at 0 dBu0.02% typically
dynamic range110 dB
Power Supply IconPower Supply
power supply voltage220 V - 110 V
power supply frequency50-60 Hz
Overall Dimensions IconOverall Dimensions
width483 mm (19")
height44 mm (1¾")
depth135 mm (5.3")
