5.7.2 Connection and setup
Optimal NomadLink performance can only be assured when
using Cat-5 cables. However, as NomadLink is only using
two wires plus ground for communication and phantom
power it is possible to create converters from RJ45 to, for
example, XLR connectors using 2-wire shielded cable. The
NomadLink network can then be operated using a standard tie-line in a
multicore signal distribution system. See the drawing opposite for an
example of how to create a converter.
If any cable format or connection other than Cat-5 (or better)
and RJ45 is utilized, network performance may be
compromised. In this event Lab.gruppen cannot guarantee
that the NomadLink network will be fully operational.
