14 CA SERIES Quick Start Guide 15
Specications
CA24 02 CA2401 CA1202 CA1201 CA602 CA601
Maximum Outpu t Power
4 or 8 Ω per channel 240 W 120 W 60 W
Number of Ouput Channels
Number 2 1 2 1 2 1
Minimun Load Impedance
4 Ω mode 4 Ω
8 Ω mode 8 Ω
70 V output mode 20 Ω 41 Ω 82 Ω
100 V output mode 41 Ω 82 Ω 166 Ω
Controls
Front Power standby button, gain control, tone controls - bass and treble
Rear Load cong - (4 Ω / 8 Ω / 70 V / 100 V), switchable 80 Hz high-pass lter
Tone Controls
Bass ±10 dB @ 100 Hz
Treble ±10 dB @ 10 kHz
Indicators
Power On (blue), force standby (red), sleep (yellow)
Master
Signal (green LED)
>12.3 mV (-36 dBu)
Limit (red LED)
Input clip, output limit
Fault (red LED)
Overheat, DC fault, over current, etc
System
Inputs
2 x 3-pin
5.08 mm Euroblock
connector
2 x RCA stereo
summed
1 x 3-pin
5.08 mm Euroblock
connector
1 x RCA stereo
summed
2 x 3-pin
5.08 mm Euroblock
connector
2 x RCA stereo
summed
1 x 3-pin
5.08 mm Euroblock
connector
1 x RCA stereo
summed
2 x 3-pin
5.08 mm Euroblock
connector
2 x RCA stereo
summed
1 x 3-pin
5.08 mm Euroblock
connector
1 x RCA stereo
summed
Input impedance 10 kΩ unbalanced and RCA, 20 kΩ balanced
Input sensitivty
Balanced: 1.23 V (+4 dBu)
RCA: 0.62 V (-2 dBu) each for mono sum RCA
Maximum input
level
9.75 V (+22 dBu)
Outputs
1 x 4-pin
5.08 mm Euroblock
connector
1 x 2-pin
5.08 mm Euroblock
connector
1 x 4-pin
5.08 mm Euroblock
connector
1 x 2-pin
5.08 mm Euroblock
connector
1 x 4-pin
5.08 mm Euroblock
connector
1 x 2-pin
5.08 mm Euroblock
connector
Output circuit type Class D
Remote connector 2 x RJ45 connector 1 x RJ45 connector 2 x RJ45 connector 1 x RJ45 connector 2 x RJ45 connector 1 x RJ45 connector
CA24 02 CA2401 CA1202 CA1201 CA602 CA601
Performance
Distortion,
1/8 rated power
<0.05%
Frequency
response
20 Hz to 20 kHz, +0.5 / -1 dB
Crosstalk
(2 channel models)
>85 dB
Signal-to-noise >97 dBA
High-pass lter 80 Hz HPF
Circuit Protection
Cooling Convection-cooled, fanless
Amplier
protection
Thermal protection, over current protection, DC protection, high frequency protection
Load protection Controlled start and shutdown behaviour, DC-fault protection
Power Supply, Voltage (Fuse)
Main voltage
100-240 V~, 50/60 Hz with
active power factor correction
100-240 V~, 50/60 Hz
Fuse T 6.3 A L 250 V T 3.15 A L 250 V
Power
consumption
1/8th rated power
@ 4 Ω
120 W 70 W 50 W 60 W 40 W
Mains connector Standard IEC connector
Dimensions / Weight
Dimensions
(H x W x D)
44 x 218 x 299 mm (1.7 x 8.6 x 11.8")
Weight 2.6 kg (5.8 lbs) 2.4 kg (5.3 lbs) 2.6 kg (5.8 lbs) 2.3 kg (5.1 lbs) 2.4 kg (5.3 lbs) 2.2 kg (4.9 lbs)
Finish Brushed black anodized aluminum chassis with black painted steel bottom
Approvals CE, cTUVus, PSE, CCC, RoHS, FCC part 15 Class B and Energy Star 3.0
