14. Appendix
14.2. Current draw and thermal dissipation
D SERIES 10:4
Level Load
Rated power
per channel
Line Current Measured Power (W) Thermal Dissipation
(A) In Out Dissipated BTU/hr kCal/hr
Mains Voltage 100 VAC
Standby
0.1 7 0 7 24 6
Power On, Idling, Green Mode
0.5 45 0 45 153 38
Power On, Idling, Performance Mode
0.7 71 0 71 241 61
Pink Pseudo
Noise
16 Ω / Ch. 250 x 4 2.3 229 125 104 355 89
8 Ω / Ch. 250 x 4 2.4 240 125 115 391 98
4 Ω / Ch. 250 x 4 2.6 254 125 129 439 111
2 Ω / Ch. 250 x 4 2.8 279 125 154 527 133
100 V / Ch. 175 x 4 1.8 179 88 92 313 79
70 V / Ch. 250 x 4 2.3 230 125 105 358 90
Mains Voltage 120 VAC
Standby
0.1 7 0 7 24 6
Power On, Idling, Green Mode
0.4 44 0 44 152 38
Power On, Idling, Performance Mode
0.6 70 0 70 238 60
Pink Pseudo
Noise
16 Ω / Ch. 250 x 4 1.9 228 125 103 350 88
8 Ω / Ch. 250 x 4 2.0 238 125 113 386 97
4 Ω / Ch. 250 x 4 2.1 252 125 127 433 109
2 Ω / Ch. 250 x 4 2.3 277 125 152 519 131
100 V / Ch. 175 x 4 1.5 179 88 91 311 78
70 V / Ch. 250 x 4 1.9 229 125 103 353 89
Mains Voltage 208 VAC
Standby
0.1 7 0 7 24 6
Power On, Idling, Green Mode
0.3 42 0 42 142 36
Power On, Idling, Performance Mode
0.4 66 0 66 225 57
Pink Pseudo
Noise
16 Ω / Ch. 250 x 4 1.1 221 125 96 328 83
8 Ω / Ch. 250 x 4 1.1 228 125 103 353 89
4 Ω / Ch. 250 x 4 1.2 245 125 120 408 103
2 Ω / Ch. 250 x 4 1.3 269 125 144 493 124
100 V / Ch. 175 x 4 0.9 174 88 86 294 74
70 V / Ch. 250 x 4 1.1 222 125 97 332 84
Mains Voltage 230 VAC
Standby
0.1 7 0 7 25 6
Power On, Idling, Green Mode
0.3 41 0 41 141 36
Power On, Idling, Performance Mode
0.3 65 0 65 222 56
Pink Pseudo
Noise
16 Ω / Ch. 250 x 4 1.0 218 125 93 317 80
8 Ω / Ch. 250 x 4 1.0 225 125 100 342 86
4 Ω / Ch. 250 x 4 1.1 238 125 113 387 97
2 Ω / Ch. 250 x 4 1.2 263 125 138 472 119
100 V / Ch. 175 x 4 0.8 168 88 81 275 69
70 V / Ch.
250 x 4 1.0 216 125 91 311 78
