SPECIFICATIONS
Lab.gruppen AB, Gullregnsvägen 16, SE-434 44 Kungsbacka, Sweden.
Tel +46 300 56 28 00 Fax +46 300 56 28 99 e-mail: info@labgruppen.com www.labgruppen.com
Max output power
1)
EIA EIA FTC
EIA at 1 kHz and 1% THD 20–20 kHz at 0.1% THD
MLS-switch –3 dB 0 dB Full 0 dB Full
16 Ω per channel 110 W 215 W 210 W
8 Ω per channel 240 W 430 W 420 W
4 Ω per channel 430 W 840 W 800 W
2 Ω per channel 870 W 1200
2)
, 1540
3)
W 1175 W
16 Ω bridged 480 W 860 W 840 W
8 Ω bridged 870 W 1680 W 1600 W
4 Ω bridged 1740 W 2400
2)
, 3000
3)
W 2350 W
Max output voltage
8 ohms load, MLS @ 0 dB 45 Vrms 59 Vrms
Peak voltage, no load 65 V 85 V
fP 2600
Distortion etc.
THD 20 Hz–20 kHz and 1 W to full power 0.04 %
THD @ 1 kHZ and –1 dB under clip 0.01 %
DIM 30 at –3 dB under clip 0.008 %
Hum and Noise <–110 dB
Channel separation @10 kHz 70 dB
Output impedance 30 mΩ
Slew Rate 60 V/s
Inputs
Gain, selectable [dB] 20, 23, 26, 29, 32, 35, 38, 41
Impedance 20 kohm
Common mode rejection 50 dB
Front Panel
Gain controls (2) channel A, B 31 positions detent
Clip Indicator (2) red LEDs
Output headroom
indicators (10) green LEDs Fast peak –slow release
Temp Indicator (2) yellow LEDs 80°C at heatsink
Protect indicator (2) yellow LEDs >12 kHz at full power
or shorted output
On Indicator (2) green LEDs DC rail voltage for
channel A and B
Rear Panel
Input connectors (2) Neutrik Combo XLR type, 3 pin
and 1/4˝ jack
Link connector (2) XLR type, 3 pin male
Output connectors (2) Neutrik 4-pole Speakon® connectors
Switches:
Clip limiter A and B On–Off (switchable)
MLS switch 0, –3 dB
Link-switch Ch. A–B
Power 230 V version 115 V version
Operation voltage 130 V–265 V AC 65 V–135 V AC
Minimum start voltage 175 V 85 V AC
Full output power
at 4 ohms 180 V–265 V AC 90 V–130 V AC
Peak inrush current
(Soft start limited) 5 A 5 A
Current Draw @ 4ohms
Quiescent power (no load) 1 Arms 2 Arms
1/8 of full power (–9 dB) 6 Arms 12 Arms
1/3 of full power (–5 dB) 9 Arms 18 Arms
At full power (0 dB) 16 Arms 32 Arms
Net Dimensions
mm 483 (19˝) W ✕ 88 H ✕ 287 D
inch 19˝ W ✕ 3.5˝ H ✕ 11.3˝ D
Shipping Dimensions
mm 560 W ✕ 180 H ✕ 500 D
inch 22˝ W ✕ 7.1˝ H ✕ 19.7˝D
Weight
Net 8 kg (18 lbs)
Shipping 9.6 kg (21.2 lbs)
Approvals
CE:
Emission EN 55 103-1, E3
Immunity EN 55 103-2, E3, with S/N below 1% at normal operation level
4)
Safety EN 60065, class I
ETL listed: Conforms to ANSI/UL STD 6500 and Certified to CAN/CSA E60065-00
FCC: Complies with Class B digital device, Part 15 of the FCC Rules.
NOTES:
1) Specifications measured with 230 V AC
2) Component tolerance dependent
3) Continuous power, one channel driven or peak power both channels driven
(Thermal protection may occur at high continuous power)
4) Normal operation level 1/8 of full power or –9 dB below clip level.
Lab.gruppen reserve the right to alter functions or the specification without prior
notice.
