Quick Start Tutorial
PLM Series Quick Start and Field Reference Guide Rev 1.3.5
▸ INPUT CONFIGURATION:
#1: Auto Type: Analog Offset/Headroom: 26 dBu
#2: Auto Type: Analog Offset/Headroom: 26 dBu
▸ DANTE CONFIGURATION:
Dante Disabled
▸ ANALOG ISO-FLOAT & AES TERMINATION:
Inputs 1-2: Floating AES: Terminated
31. Tap EVENTS & CONTROL to access various amplier specic information and options, including
four amplier attenuation controls on the STATUS tab. As a precaution, drag all four faders to the
minimum position.
32. Tap the bottom-right return button to return to I/O CONFIG.
33. Tap the INPUT GAIN block on the interactive block diagram for Module A. The LEVELS screen
displaying the gain parameters for Module A will be displayed. This screen can also be accessed by
returning to HOME and tapping the Module icon.
34. There are ve gain faders displayed (1 Module Input, 4 Module Outputs). Set the values by dragging
the fader, or by tapping the blue highlighted values at the top of the screen:
▸ INPUT: -0.00 dB
▸ LOW-1: -3.00 dB
▸ MID-2: -6.00 dB
▸ HIGH-3: -12.00 dB
▸ AUX-4: 0.00 dB
35. Tap the EQ tab at the top-left of the screen, then tap the XOVER tab. This screen shows the
frequency split settings for the 3-way crossover and can be adjusted according to manufacturer
specications or by measurement and manual tuning as required. Please refer to the Lake Controller
Operation Manual for detailed information on the XOVER screen.
36. Tap the AUX-4 tab to show the HPF/LPF and EQ settings for the Subwoofer channel. Please refer to
the Lake Controller Operation Manual for detailed information on the AUX screen.
37. Navigate to the LEVELS page by tapping the LEVELS tab at the top left of the screen.
38. Unmute the Module Input by tapping the red MUTED button; the button turns blue and reads
UNMUTED.
39. Start playback of audio through the mixing console and turn up the volume of the MAIN and SUB-
WOOFER channels from the mixing console.
To Next Page
