Labconco FreeZone 12 User Manual

50
Product Service: Domestic 1-800-522-7658, International 816-333-8811
A
ppendix A: Freeze Dryer Component
s
Item Model Part No. Description
1 6 Liter
6 Liter
6 Liter
12 Liter
12 Liter
7945500 Condensing Module 115V, 60 Hz
7945501 Condensing Module 220/240V, 50 Hz
7945502 Condensing Module 115V/ 60 Hz, PTFE-coated
7951600 Condensing Module 208/230V, 60 Hz
7951601 Condensing Module 208/230V, 60 Hz, PTFE-coated
12 Liter
18 Liter
18 Liter
18 Liter
7951602 Condensing Module 220/240V, 50 Hz
7952600 Condensing Module 208/230V, 60 Hz
7952601 Condensing Module 208/230V, 60 Hz, PTFE-coated
7952602 Condensing Module 220/240V, 50 Hz
2 w/ Shell Freezer 7734203 Condensing Module 115V, 60 Hz
w/ Shell Freezer 7734204 Condensing Module 220/240V, 50 Hz
w/ Shell Freezer 7734205 Condensing Module 208/230V, 60 Hz
3 All 7989900 Lid
4 All 7690800 Lid Gasket
5 w/ Shell Freezer 7736800 Lid, Shell Freezer
6 All 7780401 Panel, Cabinet Side
7 All 7536500 Panel Weldment, Front Access
8 All 7512300 Panel, Rear
9 w/o Shell Freezer 7772900 Cabinet Top
w/ Shell Freezer 7772901 Cabinet Top
10 no options 7513400 Enclosure Assembly, Electrical, 115V, 60 Hz
no options 7513401 Enclosure Assembly, Electrical, 230V, 50/60 Hz
w/ Purge Valve 7515901 Enclosure Assembly, Electrical, 115V, 60 Hz
w/ Purge Valve 7515902 Enclosure Assembly, Electrical, 230V, 50/60 Hz
w/ Shell Freezer 7515903 Enclosure Assembly, Electrical, 115V, 60 Hz
w/ Shell Freezer 7515904 Enclosure Assembly, Electrical, 230V, 50/60 Hz
w/ Purge Valve & Shell Freezer 7515905 Enclosure Assembly, Electrical, 115V, 60 Hz
w/ Purge Valve & Shell Freezer 7515906 Enclosure Assembly, Electrical, 230V, 50/60 Hz
11 All 7515500 PC Board
12 no options 7512800 Control Panel Label
w/ Purge Valve 7516300 Control Panel Label
w/ Shell Freezer 7516400 Control Panel Label
w/ Purge Valve & Shell Freezer 7516500 Control Panel Label
13 All 1302300 Switch
14 w/ Purge Valve 7842100 Valve Assembly, 115V, 60 Hz
w/ Purge Valve 7842200 Valve Assembly, 230V, 50/60 Hz
15 All 7728000 Drain Plug
16 All 1643600 O-Ring
17 All 7645900 Drain Hose, Collector Chamber
18 w/ Shell Freezer 7624100 Drain Hose, Shell Freezer
19 6 Liter w/ Purge Valve 7646004 Vacuum Hose, Collector Chamber to Purge Valve
12 Liter w/ Purge Valve 7646005 Vacuum Hose, Collector Chamber to Purge Valve
18 Liter w/ Purge Valve 7646002 Vacuum Hose, Collector Chamber to Purge Valve
20 All 7646000 Vacuum Hose, Vacuum Pump (Not Shown)
21 115V 1336300 Power Cord 115V (Not Shown)
22 230V 1337300 Power Cord, 230V (Not Shown)
23 All 7515200 Vacuum Sensor (Not Shown)
23A All 7515300 Temperature Sensor, Collector (Not Shown)
24 w/ Shell Freezer 7515301 Temperature Sensor, Shell Freezer (Not Shown)
