16
Product Service: Domestic 1-800-522-7658, International 816-333-8811
Chapter 3: Getting Started
Vacuum Pump Connection
A vacuum pump with a rated capacity of 113 liters per
minute is required to operate your Freeze Dry System
properly. The unit is provided with a 3/4" ID, heavy
wall, vacuum hose for connecting the vacuum pump to
the collector chamber on the unit.
Position the vacuum pump near the vacuum exhaust
port on the rear of the benchtop cabinet. For console
models, from the back of the unit, place the vacuum
pump on the floor of the cabinet. Connect the vacuum
pump power cord to the receptacle on the back of the
cabinet. If the vacuum pump has an off/on switch, turn
the switch on. The vacuum pump will be controlled by
the Freeze Dryer. Connect the vacuum pump inlet port
to the collector chamber with the vacuum hose and
clamp provided. If necessary, cut the hose to proper
length to allow for gentle bends without kinks.
Electrical Connection
Plug the power cord into the receptacle on the back of
the Freeze Dryer and plug the other end into a suitable
power receptacle.
Solvent Safety
Precautions
Solvents used in the Freeze Dryer may
be flammable or hazardous. Use
extreme caution and keep sources of
ignition away from the solvents.
!
!!
!
