Two DB-15 Aux Connectors are available
LIGHT BAR/AUXILIARY CONNECTOR
DB-15 FEMALE
P10
PIN #
INPUT/
OUTPUT
ADDRESS
+24VDC
1
+24VDC
2
24 COM
3
24 COM
4
LOW LABEL IN
5
I
X0.5
ERROR LIGHT (Red light)
6
O
Y0.6
On=GREEN Off=RED
LOW LABEL (Yellow light)
7
O
Y0.7
RUN STATUS OK (Green Light)
8
O
Green = /Red
TAMP SYNC OUT
9
O
Y1.1
INHIBIT IN
10
I
X0.6
Aux Input #2
11
I
X0.7
Aux Input #3
12
I
X1.1
Aux Input #4
13
I
X1.2
Applicator in cycle output (Applicator Busy)
14
O
Y1.2
Batch Done Aux Output #1
15
O
Y1.6
Round Module / Serial Plus Port
DB9 Female
P11
PIN #
INPUT/
OUTPUT
ADDRESS
SHIELD
1
+485 RS232 XMIT (port D) to motor
2
-485 RS232 RECV (port D) to motor
3
24C
4
24C
5
Tamp Slide / Aux Output #2 High current
6
O
Y1.7
Aux Input #2
7
I
X0.7
+24
8
+24
9
DRIVE MOTOR CONNECTOR
7 pin
P12
PIN #
24vdc High Power
A1
ENC A
1
ENC B
2
GND
3
GND
4
+5vdc
5
24vdc High Power
A2
PRINTER INTERFACE
14 pin Centronix
P9
PIN #
I/O
I/O Monitor
ADDRESS
Paper End
1
Input
X1.3
Printer Ground
2
Ribbon End
3
Input
X1.4
Printer Error
4
Input
X1.5
Print Start
5
Output
Y0.4
Print End
6
Input
X1.6
Reprint
7
Output
Y0.5
8
ONLINE (Sato Only) (Zebra Data
Ready)
9
INPUT
X1.7
Ribbon Near End
10
Input
X1.0
11
12
+5vdc From Printer
13
14
Shield
