LabelMill LM3605 - Page 16

LM3605 Print & Apply Label Applicator
USER'S MANUAL
Page 16 Made in the U.S.A.
© 2019 LABELMILL
12/01/2019 Model LM3605
ACCESSORY CONNECTIONS
LOCATED ON BACK OF LABELER CONTROL ENCLOSURE
2-07
MAIN POWER
POWER SWITCH
120VAC
FOR PRINTER
PRINTER INTERFACE
LOW LABEL WARINING
LIGHT KIT
TAMP VALVE PACK
TAMP CYLINDER
HEAD UP SWITCH
START INPUT
TAKE-UP MOTOR
FUSE
PRE-PRINT
PHOTO-EYE INPUT
