LM-3605 Dynamic Label Applicator
USERS MANUAL
Page 7 Made in the U.S.A.
© 2019 LABELMILL
12/01/2019 Model LM3605
COMPONENT
DESCRIPTION / LOCATION
1-04
THERMAL
PRINTER
WEB TAKE-UP
SPOOL
WEB GUIDE
ROLLERS
TAMP
CYLINDER
LABEL SPOOL
SPOOL LOCK
U-ARM
VALVE PACK
AIR FILTER/
REGULATOR
SWING AWAY
TAMP ASSEMBLY
BRAKE ARM
REED SWITCH
AIR ASSIST
TUBE
ALARM
STACK
