BTA 060, Rev 1K1 Page 12/18
Figure 11: Operator actions for correcting the zero point
6.3.3 Min. and max. pointers ( Lo / Hi )
The device has min./max. pointers for minimum and maximum pressure values. You can
display and reset them in this menu. Resetting a pointer is confirmed by showing "----"
on the display.
Display Designation Description
Value of min./max
pointer
Value of min./max. pointer in the selected
measuring unit
Clear Reset the stored pointer value
Return
Return to "Lo" or "Hi"
Table 7: Parameter list for min./max. pointer
The steps needed to reset the minimum pointer are shown below.
> 2 s
> 1 s
Figure 12: Operator actions to reset the minimum pointer
