Installation
Please check all parts and accessories before installation and setup according to the following.
Site Requirements
Ambient Temperature Range: 10°C to 40°C (50°F to 104°F)
Relative Humidity Range: 10% to 80% (non-condensing)
Operating Altitude: Sea Level to 8000 feet (2438 meters)
Never place the unit in a location where excessive heat, moisture, or corrosive materials are present.
Please put the equipment on a firm, strong bench. Avoid the resonance from the bench. This will decrease the
risk of vibrations and noise.
Dimensions and Weights
Unit
High (cm)
Width (cm)
Length (cm)
Diameter (cm)
Weight (Kg)
EV400H
64
44
55
-
17
EV400
64
44
55
-
25
EV400Touch
66
47
58
-
25
EV400VAC
66
47
58
-
25
HB-03 Thermal Bath
-
-
-
33
4
Electrical Requirements
The unit provides extra protection against the risk of electrical shock by grounding appropriate metal parts. The
extra protection may not function unless the power cord is connected to a properly grounded socket. It is the
user’s responsibility to assure a proper ground connection is provided. The unit is supplied with a European power
cable. It is used to relate to power supply. Plug the cord into socket and plug the rear into electric socket of the
unit. Then the unit is ready to be used.
The following power options are available:
UNIT
Voltage (V)
Frequency (Hz)
Fuse
IP Degree
Power Consumption (W)
EV400H
230
50/60
10
21
100
115
60
10
21
100
EV400
230
50/60
10
21
100
115
60
10
21
100
EV400Touch
230
50/60
10
21
150
115
60
10
21
150
EV400VAC
230
50/60
10
21
150
115
60
10
21
150
HB-03 Thermal
Bath
230
50/60
10
21
1300
115
60
10
21
1300
