Ultimate-cell Stackable Shaking Incubator V2017.2
17
5.10.6 Loosen the (C) safety nut with 17*19 spanner
5.10.7 Use the 8*10 spanner to rotate the (B) adjusting bolt clockwise to decrease
the shaking diameter, but anti-clockwise to increase.
5.10.8 When adjustment is done, tighten the (B) adjusting bolt and (A) central Allen
screw.
5.10.9 Install the base tray and shaking tray back in place.
Chart of Ratio Between Speed and Shaking Diameter
Attention:
The maximum shaking speed should decrease when the shaking
diameter is increased. Please see the chart below for the chart of ratio
between speed and shaking diameter.
.
