4.2.2.Engine starting procedure
EQUIPMENT
33
WARNING
In the event of a failure, there is a 3-way
backup panel in the engine room: START
/ SPEED POTENTIOMETER / FORWARD/REVERSE
BUTTON.
WARNING
If the backup panel is ON, all helm station
controls are blocked.
- SWITCH OFF THE BACKUP PANEL IN THE ENGINE
ROOM,
- CUT THE SUPPLY TO THE ENGINES FOR 10+ SECONDS,
THEN SWITCH BACK ON.
In backup mode:
If the engine start batteries are not available, a coupling
system of the port and starboard.
starting batteries can be used to start the engines and
generators.
Helm station control panels are powered by the engine ECU.
This ECU is powered up when the engine cut-outs are
triggered.
In normal mode:
1- Switch on the engines
2 - Switch on the control panels
3- Press START
