4.4.5.Location of the battery cut-outs, electrical panels and appliances
CF8 type fuses are placed directly between the busbar and the crimped lug on the cable.
Some equipment shown on the panel below may be optional.
4.4.4
.Emergency starting
If the engine batteries are not available, a coupling system of the port and starboard 12 V starting batteries is available.
To select the battery coupling:
- Activate (position ON) the general cut-out, the port and starboard engine cut-outs, and then the coupling cut-out, located in
the port engine compartment.
This coupling can be activated remotely via the panel in the port companionway.
- Start the port and starboard engines.
- Once the engines are running, close (position OFF) the coupling cut-out.
Note: in a normal configuration, the 12 V engine starting batteries would then be charged by the engines' 12 V alternators.
ATTENTION
Before replacing a fuse, switch off the
battery cut-outs.
