6
60
HOISTING AND TRANSPORT
6.1 . DIAGRAM, DIMENSIONS AND POSITIONS OF THE HOISTING BELTS
6. HOISTING AND TRANSPORT
ATTENTION
Make sure that the boat is stable on its tow
lines, both lengthways and widthways.
ADVICE - RECOMMENDATION
Get a diver to intervene for the strainers
and sea cocks.
The necessary hoisting belts are described below:
Two rudder bars with two 300 millimetre straps and 50 tonnes each (total capacity - 100 tonnes).
3250 mm
850 mm
6400 mm
2050 mm
210 mm
10864 mm
