EQUIPMENT
41
24V CIRCUIT (main panel starboard saloon companionway)
24 V GENERAL DISTRIBUTION CIRCUIT
To Port E/R busbar
General service busbar
X69 - port hull in the
forward guest cabin
Main Busbar X01
General Service Busbar
X02
General Service Busbar
starboard hull X71 in
the VIP below-deck
area of the VIP cabin
Bow thruster
To starboard E/R
busbar
UNDER THE
SALOON
FLOOBOARDS
ROOF FUSE
BOXES
CHART TABLE
FUSE BOX
FUSE BOX -
PORT HULL
AND BILGE
PUMPS
FUSE BOX -
STARBOARD
HULL AND
BILGE
PUMPS
Battery set
630 Ah
Battery set
420 Ah
VIP cabin
VIP cabin
below-deck
VIP cabin stairway
PORT FUSE
BOXES
F.O.
Pump
relay
Watermaker
controls
Windlass
relay
X05
X69
X02
X01 MAIN BUSBAR
X71
X62
STANDARD FUSE BOXES
Battery
discon-
nection
switches
Battery
Switch
Remote
Control
Battery
Switch Re-
mote Control
K01
Charger
100A-24V
U01
Charger
100A-24V
U02
Charger
100A-24V
U03
ISO U05 CONVERTER
ISO U06 CON-
VERTER
ISO U07 CON-
VERTER
