LIST OF PROTECTION RATINGS
NAME DESCRIPTION DESIGNATION
Q-01 PC COMFORT f10 20 A
Q-02 BATTERY CHARGER Z50-Z60 20 A
Q-03 HIFI VIDEO F10 16 A
Q-04 HIFI VIDEO F20 16 A
Q-05 GALLEY FRIDGE K50/K30 16 A
Q-06 WASHER DRYER 20 A
Q-07 PC COMFORT F20 20 A
Q-08 DISHWASHER 20 A
Q-09 INDUCTION PLATE 32 A
Q-10 PC COMFORT H35 20 A
Q-11 PC 10mA F10 20 A
Q-12 PC 10mA F20 20 A
Q-13 ICE MAKER 16 A
Q-14 GRILL-PLANCHA 16 A
Q-15 OVEN 20 A
Q-16 HOOD / COFFEE MAKER / MICROWAVE 20 A
Q-22 WATER HEATER F10 16 A
Q-23 WATER HEATER F20 16 A
Q-25 WATERMAKER Z60 25 A
Q-27 ELECTRIC HOUSEHOLD EQUIPMENT H35 16 A
Q-37 AERATION HANDLE F10 10 A
Q-38 AERATION HANDLE F20 10 A
Q-39 AERATION HANDLE H35 10 A
Q-46 SERVICE BATTERIES CHARGER #1 20 A
Q-47 SERVICE BATTERIES CHARGER #2 20 A
Q-48 SERVICE BATTERIES CHARGER #3 20 A
Q-54 WASTEWATER P10 16 A
NAME DESCRIPTION DESIGNATION
I-02 10 mA DIFF BREAKER 25 A 10 mA
I-03 10 mA DIFF BREAKER 25A 10mA
NAME DESCRIPTION DESIGNATION
FUSE 01 INDICATOR LIGHT 5x20 FUSE 100 mA
FUSE 02 INDICATOR LIGHT 5x20 FUSE 100 mA
FUSE 06 INDICATOR LIGHT 5x20 FUSE 100 mA
FUSE 08 INDICATOR LIGHT 5x20 FUSE 100 mA
