4 Display and Operational Controls
4 Display and Operational Controls
To display and operate LT3, the user interface is integrated into the front door of LT3 (included
in the standard).
Functions:
• Reading of the O
2
measured values
• Password entry
• Information regarding the probe, fuel, warnings, faults, software version,
CRC, and serial number
• Calibration of measurement
• Settings maintenance, filter time, analogue output, probe replacement, display,
limit values, and digital outputs
Fig. 4-1 LT3 user interface
Fig. 4-2 Housing with user interface
