Lamtec KS1D User Manual

49
8 Options
8.3.2 Factory Settings of the Digital Inputs
NOTICE
Manual activation of the relay outputs:
Position 1  input always activated
Position A  input switches via external contact with 24 VDC
Position 0  input always deactivated
8.3.3 Diagnosis of the Digital Inputs
4 LEDs above the switches indicate the switching state of the digital outputs.
Digital input 1 Trigger OFFSET CALIBRATION
Digital input 2 RESET FAULT
Digital input 4 DEACTIVATION LIMIT VALUE 1 ... 4
Digital input 5 RESET LIMIT VALUE 1 ... 4
Digital input 8 DEACTIVATION CALIBRATION
