16
4 Display and Operational Controls
4.3 Status Line
The status line contains information about LT3, including the device family.
Fig. 4-3 UI300-LT-V2 front view status line
1. Status line
Description status line:
Active fault/warning
Operating mode OK
Heat-up (cold start)
Status of limit values 1-4
*
Active limit value not triggered
Non-active limit value (off)
Active limit value undershot/exceeded
Active maintenance mode
Without access level
Access level 1 - Customer
Access level 2 - Service
Window number
*
If a limit value is exceeded the display shows an upward or downward arrow.
