P A R T S PAGE 25
Last printed 1/31/2012 4:04:00 PM
Version Rev. 2003D-0
Frame Assembly
Ref.
Nr. Item Nr. Item Nr. Quantity Description
1 250-1 49 04 40 1 Each Main Wrap
2 LT15-2 49 04 41 1 Each Left Side Panel
3 250-3 49 04 42 1 Each Right Side Panel
4 250-4 49 04 43 1 Each Motor Support
5 250-5 49 04 44 2 Each Back Angle
6 250-6 49 04 45 2 Each Side Cover Panel
8 250-34 49 04 47 4 Each Rear Backing Plate
9 250-35 49 04 48 4 Each Front Backing Plate
10 250-16 49 04 49 1 Each Brace
11 250-38 49 04 50 2 Each Bearing Support
12 CS4W890 49 01 85 2 Each Rigid Caster
13 CS4W887 49 01 86 2 Each Swivel Caster
14 BOS0AB240125 49 04 51 8 Each 3/8 – 16 x 1¼-in. Carr Bolt SS
16 BOSAU160125 49 04 53 17 Each 10-24 x 1¼-in. PH RHMS SS
17 RNA1024A080 49 04 54 10 Each 10-24 Aluminum Riv Nut
19 BOS0AH220075 49 04 55 16 Each 3/8 – 16 x ¾-in. HHCS SS
20 WASGA037 49 03 71 16 Each 3/8-in. Std. Flat Washer SS
21 WASGAI037 49 04 56 16 Each 3/8-in. Std. Lock Washer SS
22 NUS0EA24 49 04 57 16 Each 3/8 – 16 Hex Nut SS
23 BOS0AA200100 49 03 80 13 Each ¼ - 20 x 1-in. HHCS SS
24 WASGI025 49 03 93 13 Each ¼-in. Std. Lock Washer
To Next Page
