Lance LT-30 - Vacuum Assembly Parts

P A R T S PAGE 26
Last printed 1/31/2012 4:04:00 PM
Version Rev. 2003D-0
Vacuum Assembly
Ref.
Nr. Item Nr. Item Nr. Quantity Description
1 250-36TW 49 04 58 1 Each Trap Bracket
2 VU607CE32 49 04 59 1 Each Vacuum Pump
3 VTAA672K 49 01 43 1 Each Ball Trap
4 BOSOAU140037 49 04 60 3 Each 8 – 32 x 3/8-in. PH RHMS SS
5 BOSOAU160050 49 04 61 3 Each 10 – 24 x ½-in. PH RHMS SS
6 TEE101C 49 01 46 1 Each Tee
7
HN5346K18
49 01 45
1 Each
Male Hose Nipple
8 OR9464K26 49 01 32 1 Each O-Ring
9 HN5372K11 49 01 68 1 Each Male Hose Nipple
10 HN5372K12 49 04 62 2 Each Male Hose Nipple
11 HS26-705AM 49 01 40 16 Inches 3/8-in. Hose
12 HS26-702AM 49 01 47 6 Feet ¼-in. Hose
13 EL116SC 49 01 30 2 Each 90˚ Street Elbow
14 0002-49 49 01 38 1 Each Vacuum Plug
15
VTAJ554
49 01 15
1 Each
Trap Ball
16 VTAJ473 49 01 33 1 Each Trap Funnel
17 VTAE274 49 01 16 1 Each Trap Jar
18 HN5346K42 49 01 44 1 Each Female Hose Nipple
19 GATSUGF 49 01 34 1 Each Vacuum Gauge
