LANDA PDE • 8.913-997.0 • Rev. 02/12
15
PRESSURE WASHER
OPERATOR’S MANUAL
ITEM PART NO. DESCRIPTION QTY
55 9.802-454.0 Switch Assembly (2-11024D) 1
56 8.932-969.0 Label, Warn, Service Cord 1
57 9.802-516.0 Strain Relief, Flex 90°, Plastic
(2-15024D) 1
9.802-525.0 ▲ Locknut, 1/2" Conduit
(2-15024D) 1
58 9.802-514.0 Strain Relief
(2-11024D) 1
9.802-525.0 ▲ Locknut, 1/2"
(2-11024D) 1
59 99.802-695.0 ▲ Nut, 10/32" Keps (2-15024D
4-20024A) 3
9.802-699.0 ▲ Screw, 10/32" x 3/4" Slot Pan,
MS SS (2-15024D 4-20024A)1
9.800-040.0 ▲ Label, Ground (2-15024D,
4-20024A) 1
60 9.802-695.0 Nut, 10/32" Keps (4-20024A) 4
61 9.803-832.0 Conduit, Water Tite, Flex 3/4"
(4-20024A) 8"
62 9.802-436.0 Cord, Service, 10/3 (4-20024A,
352007A) 21"
63 9.802-776.0 Nut, 5/16" ESNA 4
64 9.802-518.0 Strain Relief 3/4" 1
9.802-523.0 ▲ Locknut, 3/4" (4-20024A) 1
65 9.800-049.0 Label, Manufacturer's Cleaning
Solution 1
66 9.800-040.0 ▲ Label, Ground (Motor) 1
67 9.802-810.0 Washer, 5/8" Flat 2
68 9.803-834.0 ▲ Washer, Reducing, 3/4" x
1/2" (2-15024D) 1
▲ Not Shown
2-11024D, 2-15024D, 4-20024A EXPLODED VIEW PARTS LIST
