Landa PDE4-2000 - Parts List: Models 4-30025 A;B;C

LANDA PDE • 8.913-997.0 • Rev. 02/12
17
PRESSURE WASHER
OPERATOR’S MANUAL
ITEM PART NO. DESCRIPTION QTY
1 9.803-114.0 Retainer, Bracket 2
2 8.706-864.0 Plug, 1/8" Countersunk 1
3 9.802-434.0 Cord w/GFCI, 240V, 40 Amp
TRC (4-3000A) 1
9.802-437.0 Cord, Service, SEO 10/4
(4-3000B) 15 ft.
9.802-429.0 Cord, Service 12/4
(4-3000C) 15 ft.
4 9.803-123.0 Handle, Bumper, Chrome 1
5 9.800-040.0 Label, Ground 1
6 8.724-305.0 Overload, 24-32 Amp
(4-3000B) 1
8.724-312.0 Overload, 10.00- 16 Amp
(4-3000C) 1
7 9.800-015.0 Label, Warning, Service
Cord 1
8 9.803-122.0 Handle, Grab, Chrome 1
9 9.802-457.0 Din Rail, 35mm 4"
10 9.803-119.0 Handle, Lower Grab,
Chrome 1
11 9.802-695.0 ▲ Nut, 10/32" KEPS
(4-3000A) 6
(4-3000B, C) 4
9.802-762.0 ▲ Screw, 10/32" XD 1-1/4" 1
9.802-759.0 ▲ Screw, 10/32" x 1/2",
BHSOC B1 (4-3000A) 7
(4-3000B, C) 5
12 9.802-064.0 Grommet, 1/8" Rubber 5
13 9.802-066.0 Pad, Soft Rubber, 50 Duro 2
14 9.802-170.0 Nipple, 3/8" x 3/8" NPT ST
Female 1
15 8.707-256.0 Pump Protector, 1/2" PTP 1
16 9.802-270.0 Wheel, 4" Steel Rim 2
17 8.712-345.0 Nozzle, SAQMCEG 0004
Red 1
8.712-346.0 Nozzle, SAQCMEG 1504,
Yellow 1
8.712-347.0 Nozzle, SAQMCEG 2504
Green 1
8.712-348.0 Nozzle, SAQMCEG 4004
White 1
18 8.712-398.0 Nozzle Compl, QCEM-6540
w/Black Nylon 1
19 8.715-098.0 Motor 7.5 HP 1 PH C-Face
1725RPM, 37N07X177
(4-30025A) 1
8.715-103.0 Motor 7.5 HP 3 PH C-Face
1725 RPM, 37B12X54G1
(4-30025B, C) 1
20 8.715-304.0 Pump, AR RKA35G30E-F17 1
21 9.802-729.0 Bolt, 3/8" x 2-1/4" 2
22 8.715-480.0 Unloader, AR-3-5 5 GPM,
3650 PSI, Black Knob 1
ITEM PART NO. DESCRIPTION QTY
23 9.803-974.0 Switch, GRN PB, CH 1
24 9.803-973.0 Switch, Red PB, CH 1
25 8.716-271.0 Enclosure, Fiberglass,
NEMA4X 1
26 8.900-315.0 Label, PE Off/On, For Push
Buttons 1
27 9.800-016.0 Label, Disconnect Power
Supply 1
28 9.802-720.0 Bolt, 3/8" x 1", NC HH 6
29 9.802-728.0 Bolt, 3/8" x 2", NC HH 4
30 9.197-003.0 Nut, 3/8", ESNA, NC 12
31 9.802-534.0 Block, Contact, N/C 1
32 9.802-807.0 Washer, 3/8", SAE, Flat 18
33 9.802-782.0 Collar, 5/8" Bore Shaft, 3010 2
34 9.802-817.0 Washer, 3/8" x 1" Steel 2
35 9.803-124.0 Base 1
36 9.800-013.0 Label, Indoor Use 1
9.800-034.0 Lexan, Clear 1
37 9.802-706.0 Bolt, Carriage 1/4-20 x 1-3/4
Zinc 6
38 9.802-712.0 Bolt, Carriage 5/16 x 1-3/4 4
39 9.802-103.0 Bushing, 5/8" Snap 2
40 8.920-220.0 Axle, 5/8 x 21.5" 1
41 9.802-518.0 Strain Relief, Strt, LQ Tite 1
9.802-526.0 Locknut, 3/4", Conduit 1
42 9.802-518.0 Strain Relief, STRT, LQ Tite
(4-3000B, C) 1
9.802-521.0 Strain Relief, 3/4", Water Tite
(4-3000A) 1
9.802-526.0 Locknut, 3/4" Conduit 1
43 8.724-282.0 Contactor, 240V, CH,
CE15HNS3BB-09 (4-3000A) 1
8.724-273.0 Contactor, 240V, CH,
CE15ENS3BB (4-3000B) 1
8.724-271.0 Contactor, 480V, CH
CE15DNS3CB (4-3000C) 1
44 8.900-319.0 Label 1
45 8.920-219.0 Bracket, Electrical Box 1
46 9.802-535.0 Block, Contactor, N/O 1
47 9.802-736.0 Bolt, 1/2" x 1-1/2" NC HH 4
48 9.803-517.0 Washer, 1/2" Lock 4
49 9.803-126.0 Plate, Black 1
50 9.803-098.0 Hanger, Hose & Wand 1
51 9.802-425.0 Cord, Service, 8/3
(4-3000A) 2.75 ft.
9.802-429.0 Cord, Service, 12/4
(4-3000C) 2.75 ft.
9.802-437.0 Cord, Service 10/4
(4-3000B) 2.75 ft.
4-30025A, B, C EXPLODED VIEW PARTS LIST
