LANDA PDE • 8.913-997.0 • Rev. 02/12
OPERATOR’S MANUAL
PRESSURE WASHER
18
ITEM PART NO. DESCRIPTION QTY
52 9.802-788.0 Nut, 5/16" Whiz Loc Flange 2
53 9.802-776.0 Nut, 5/16" ESNA NC 4
54 8.718-980.0 Washer, 5/16" Flat, SAE 4
55 9.802-773.0 Nut, 1/4" ESNA, NC 6
56 9.802-802.0 Washer, 1/4" Flat 6
57 9.802-518.0 Strain Relief, 3/4" LQ Tite
(4-3000A) 1
9.802-526.0 Locknut, 3/4" (4-3000A) 1
9.803-279.0 Strain Relief, 1" (4-3000B, C) 1
9.803-280.0 Locknut, 1" (4-3000B, C) 1
58 9.800-049.0 Label, Manufacturer's Cleaning
Solution 1
59 9.802-810.0 Washer, 5/8" Flat 2
60 9.802-225.0 Injector, Chem., Assy.
3-5 GPM 1
61 8.919-593.0 Axle Spacer Black Wrinkl 1
Direct Frame
▲ Not Shown
4-30025A, B, C EXPLODED VIEW PARTS LIST
