LANDA PDE • 8.913-997.0 • Rev. 02/12
OPERATOR’S MANUAL
PRESSURE WASHER
14
2-11024D, 2-15024D, 4-20024A EXPLODED VIEW PARTS LIST
ITEM PART NO. DESCRIPTION QTY
1 Model 2-15024D
9.104-016.0 NOZZLE KIT 3.25 (23326) 1
Model 2-11024D
9.804-626.0 Nozzle, 700375, White 1
9.804-624.0 Nozzle, 150375, Yellow 1
9.804-625.0 Nozzle, 250375, Green 1
9.804-627.0 Nozzle, 000375, Red 1
Model 4-20024D
8.712-354.0 Nozzle, 1505, Yellow 1
8.712-355.0 Nozzle, 2505, Green 1
8.712-356.0 Nozzle, 4005, White 1
8.712-353.0 Nozzle, 0005, Red 1
8.712-398.0 Nozzle, Compl. QCME 6540,
Brass, All 1
2 9.802-220.0 Wand, 18" M22 x 1/4" QC 1
3 9.802-223.0 Spray Gun, SK@, 3/8" Inlet,
Lance w/M22 Coupler 1
4 Hose, See Specifi cations Page
5 9.802-517.0 Connector, 1/2" L/T, 90°,
Black (2-15024D) 2
6 9.802-427.0 Cord, Service, SOWA 12/3,
Coleman (2-15024D) 21"
7 9.802-448.0 Conduit, Watertight, Flex,
1/2 (2-15024D) 8"
8 9.802-773.0 Nut, 1/4" ESNA, NC 6
9 9.802-225.0 Inj., Chem, Assy, 3-5 GPM 1
10 9.803-831.0 Connector, 3/4" L/T, 90°, Black
(4-20024A) 2
11 9.802-759.0 Screw, 10/32" x 1/2" BHSOC
Black (2-15024D, 4-20024A) 4
12 9.802-450.0 Switch, 2 Pos. 120V-600V,
1-3 PH Bremas (2-15024D,
4-20024A) 1
13 9.802-478.0 Lid, Plastic, Carlon E9801
Box (2-15024D, 4-20024A) 1
14 9.802-477.0 Box, Plastic, Carlon E9801,
w/o Lid (2-15024D,4-20024A)1
15 9.802-430.0 GFCI, 240V 1Ph 30A, 36' 10-3
Cord (4-20024A) 1
9.802-431.0 GFCI, 120V 20A, w/36' 12-3
Cord (2-15024D) 1
9.802-432.0 GFCI, 120V 15A, w/36'
12-3 Cord (2-11024D) 1
16 9.800-016.0 Label, Disconnect Power
Supply 1
17 9.803-833.0 Cover, Motor (2-15024D,
4-20024A) 1
ITEM PART NO. DESCRIPTION QTY
18 9.802-171.0 Nipple, 3/8" x 3/8" NPT ST
Male 1
19 9.802-146.0 Swivel, 1/2" MP x 3/4" GHF,
w/Strainer 1
20 9.804-025.0 Protector, Pump 1/4" PTP 1
21 Unloader, See Specifi cations Page
22 Pump, See Specifi cations Page
23 9.802-720.0 Bolt, 3/8" x 1" NC 4
24 9.802-807.0 Washer, 3/8" SAE, Flat 4
25 8.718-618.0 Bolt, 5/16" x 3/4" NC 4
26 8.718-980.0 Washer, 5/16" Flat 8
27 Motor, See Specifi cations Page
28 9.802-064.0 Grommet, Rubber, Nozzle
Holder 5
29 9.802-788.0 Nut, 5/16" Whiz Loc Flange 2
30 8.920-262.0 Handle, Grab, Chrome 1
31 8.900-319.0 Label, Landa Cold Water 1
32 9.803-126.0 Plate, Warning/Instr. 1
33 9.803-098.0 Hanger, Hose/Wand 1
34 9.802-706.0 Bolt, Carriage, 1/4"-20 x
1-3/4" 6
35 9.802-802.0 Washer, 1/4" Flat 6
36 9.802-776.0 Nut, 5/16" ESNA, NC 4
37 8.920-261.0 Handle,
Lower Grab, Chrome 1
38 9.803-114.0 Retainer Bracket, Handle,
Black 2
39 9.802-728.0 Bolt, 3/8" x 2" 4
40 9.802-730.0 Bolt, 3/8" x 2-1/4" 2
41 9.802-817.0 Washer, 3/8" x 1" 2
42 9.802-066.0 Pad, Soft Rubber, 50 Duro 2
43 9.802-807.0 Washer, 3/8" SAE, Flat 6
44 9.197-003.0 Nut, 3/8" ESNA, NC 6
45 9.802-782.0 Collar, 5/8" Bore Shaft, 3010 2
46 9.802-270.0 Wheel & Tire Assy., 4" Steel
Rim w/Tube 2
47 9.802-103.0 Bushing, Snap, 5/8" 2
48 9.802-712.0 Belt, Carriage 5/16" x 1-3/4" 4
49 9.803-097.0 Axle, 5/8" x 19.625" Long 1
50 8.718-980.0 Washer, 5/16" Flat, SAE 4
51 8.920-263.0 Handle, Bumper, Chrome 1
52 9.803-125.0 Base, CW Direct, Black 1
53 9.800-013.0 Label, Intend. For Indoor Use 1
54 9.800-034.0 Label, Clear Lexan, 2-1/4” x
4-1/2" 1
To Next Page
