LE.1 SERIES PUMP EXPLODED VIEW PARTS LIST
ITEM PART NO. DESCRIPTION QTY
36 9.804-584.0 Flange Screw 4
37 9.804-585.0 Crankshaft Seal 1
38*
See Kit Below Plunger Nut 3
39*
See Kit Below Copper Spacer 3
40*
See Kit Below Plunger 15mm (2020F,
2825F, 3525F) 3
See Kit Below Plunger 18mm
(2020S, 2825S) 3
41*
See Kit Below Copper Spacer 3
42*
See Kit Below O-Ring Ø1.78 x 5.28 3
43*
See Kit Below Tefl on Ring 3
44 9.803-964.0 Plunger Rod 3
45
9.803-965.0 Connecting Rod Pin 3
46
9.803-966.0 Connecting Rod 3
47 9.803-218.0 Spring Washer 6
48 8.933-020.0 Connecting Rod Screw 6
49 9.803-969.0 O-Ring Ø2.62 x 107.62 1
50 9.803-968.0 Crankcase Cover 1
51 9.803-197.0 Gasket 1
52 9.803-202.0 Sight Glass 1
REPAIR KIT
NUMBER 8.725-354.0 8.725-350.0 8.725-355.0 8.725-357.0 9.803-934.0 9.803-935.0 9.803-936.0 9.803-937.0
KIT DE-
SCRIPTION
Plunger
Seal
15mm
2020F.1
2825F.1
3525F.1
Plunger
Seal 18mm
2020S.1
2825S.1
Complete
Seal Pack-
ing 15mm
2020F.1
2825F.1
3525F.1
Complete Seal
Packing 18 mm
2020S.1
2825S.1
Plunger
15mm
2020F.1
2825F.1
3525F.1
Plunger
18mm
2020S.1
2825S.1
Complete
Valve
Plunger Oil
Seals
ITEM
NUMBERS
INCLUDED
3, 5, 7 3, 5, 7
3, 4, 5,
6, 7
3, 4, 5, 6, 7
38, 39, 40,
41, 42, 43
38, 39, 40,
41, 42, 43
11, 12, 13 2
NO. OF
CYLINDERS
KIT WILL
SERVICE
331 1 1 1 6 3
