LANDA PDE • 8.913-997.0 • Rev. 02/12
23
PRESSURE WASHER
OPERATOR’S MANUAL
RKA PUMP EXPLODED VIEW PARTS LIST
ITEM PART NO. DESCRIPTION QTY
30 1380120 0,10 mm Shim 1-3
1380130 0,20 mm Shim 1-3
1380530 0,25 mm Shim 1-3
1382810 0,05 mm Shim 1-3
31 740290 O-Ring 3
32 1980740 Plug 3/8” G 2
33 1260470 Screw 4
34 1380141 Base 2
35 1980740 Plug 3/8” G RKA 1
1981180 Plug 3/8” G Nickel RKAH 1
36 180101 O-Ring 1
37 820361 Plug 1/2” G RKA 1
960870 Plug 1/2” G Nickel RKAH 1
38 1381071 Pump Head Ø18 RKA 1
1381070 Pump Head Ø18 RKAH 1
1380020 Pump Head Ø20 RKA 1
1383010 Pump Head Ø22 RKA 1
1383310 Pump Head Ø22 RKAH 1
39 820150 Screw 8
40 2280260 Hollow Shaft 1
2280200 Hollow Shaft 1
2280270 Hollow Shaft 1
2280280 Hollow Shaft 1
ITEM PART NO. DESCRIPTION QTY
41 1380320 Bearing 1
42 621170 Seal 1
43 1380220 O-Ring 1
44 1380210 Shaft Cover 1
45 1380360 Electric Motor Flange 1
46 620610 Screw 4
47 1381850 Washer 8
48 1389270 Pump Head Assem Ø18
RKA 1
1389272 Pump Head Assem Ø18
RKAH 1
1389208 Pump Head Assem Ø20
RKA 1
1389268 Pump Head Assem Ø22
RKA 1
1389269 Pump Head Assem Ø22
RKAH 1
49 1080401 Ring 1
50 1260250 Oil Indicator 1
51 1260430 Snap Ring 1
52 1780690 Disc 1
53 1140450 O-Ring 1
LEGEND
018 018 020 022
For ❍ For ❒ For ▼ For ◆
RKA3.5G25
RKA3.5G30
RKA3.5G30H
RKA4G20
RKA4G30
RKA4G30H
RKA5.5G13 RKA6.5G13
RKA6.5G20H
For ●
RKA7G13
RKA7G20H
REPAIR KITS
Water Seals Valve Pistons Oil Seals Support Rings
Kit 1857018
Kit 1887020
Kit 1888022
Kit 2864 Kit 2546018
Kit 2547020
Kit 2759022
Kit 1856 Kit 1829018
Kit 1815020
Kit 1816022
Item# Qty Item# Qty Item# Qty Item# Qty Item# Qty
8 3 36193123 7 3
10 3 46203152
11 3 213271
223421
233431
49 3
SPECIAL PARTS
PART NO. DESCRIPTION QTY
2819 Kit for up to 180° F 018 High Temp 1
2820 Kit for up to 180° F 020 High Temp 1
2809 Viton water seals 018 1
2810 Viton water seals 020 1
2811 Viton water seals 022 1
