PG SERIES PRESSURE WASHER OPERATOR’S MANUAL
LANDA PG • REV. 9/02
ITEM PART NO. DESCRIPTION QTY
38 4-12804015 Nozzle, SAQCMEG 1504, Yellow
(PG4-30321, PG4-35321,
PG4-30325, PG4-35325) 1
4-12804025 Nozzle, SAQCMEG 2504, Green
(PG4-30321, PG4-35321,
PG4-30325, PG4-35325) 1
4-12804040 Nozzle, SAQCMEG 4004, White
(PG4-30321, PG4-35321,
PG4-30325, PG4-35325) 1
4-12805000 Nozzle, SAQC Meg 0005 Red
(PG4-25321, PG4-25325) 1
4-12805015 Nozzle, SAQC Meg 1505 Yellow
(PG4-25321, PG4-25325) 1
4-12805025 Nozzle, SAQC Meg 2505 Green
(PG4-25321, PG4-25325) 1
4-12805040 Nozzle, SAQC Meg 4005 White
(PG4-25321, PG4-25325) 1
4-12805500 Nozzle, SAQC Meg 00055 Red
(PG4-20321, PG4-20325) 1
4-12805515 Nozzle, SAQC Meg 15055 Yellow
(PG4-20321, PG4-20325) 1
4-12805525 Nozzle, SAQC Meg 25055 Green
(PG4-20321, PG4-20325) 1
4-12805540 Nozzle, SAQC Meg 40055 White
(PG4-20321, PG4-20325) 1
4-12806000 Nozzle, SAQC Meg 0506 Red
(PG4-15321, PG4-15325) 1
4-12806015 Nozzle, SAQC Meg 1506 Yellow
(PG4-15321, PG4-15325) 1
4-12806025 Nozzle, SAQC Meg 2506 Green
(PG4-15321, PG4-15325) 1
4-12806040 Nozzle, SAQC Meg 4006 White
(PG4-15321, PG4-15325) 1
39 5-2304 Pump, T-1011(PG4-20321) 1
5-2307 Pump, TS-2021
(PG4-25321, PG4-35321) 1
5-2335 Pump, TS-1511 (PG4-30321) 1
5-2302 Pump, Gen T991 (PG4-15321) 1
5-2270 Pump, AR XRA4G2ON
(PG4-15325, PG4-20325) 1
5-2271 Pump, AR XRCA4.5G30HN
(PG4-25325, PG4-30325,
PG4-35325) 1
45 90-1016 Bolt, 3/8" x 1", NC 4
47 90-2002 Nut, 3/8", ESNA, NC 4
48 90-4002 Washer, 3/8", SAE, Flat 6
ITEM PART NO. DESCRIPTION QTY
51 5-3208 Unloader, AL607, 7.8 GPM @
4200 PSI 1
5-3203 Unloader, AR (PG4-15325,
PG4-20325, PG4-25325,
PG4-30325, PG4-35325) 1
55 2-1902 ▲ Strainer, Inlet Garden Hose 1
56 10-02025A Label, Hot/Caliente 1
57 10-02029 Label, Danger Cool Engine 1
58 10-99081 Label, Prop. 65 Warning 1
59 90-1015 Bolt, 3/8" x 3/4", NC HH 1
60 2-0108 Bumper Pad Engine 1
61 90-4001 Washer, 5/16", Flat, SAE 8
62 90-2002 Nut, 3/8", ESNA NC 4
63 90-2001 Nut, 5/16" ESNA 3
64 2-30082 Pump Protector, 1/2" PTP 1
65 95-07101219 Bracket, Wide Foot 1
66 2-2007 Nipple, 3/8" x 3/8" NPT St. Male1
67 90-40125 Washer, 3/8" x 1" Steel 2
68 2-0107 Bellows, LEG (Boot) 2
69 90-5009 Spring, Foot Compression 2
70 95-07161114A Tube, Foot Bolt 2
71 2-3100543 Valve, EZ Start (4-1500) 1
2-3100544 E-Z Start Valve (4-2000, 4-2500,
4-3000, 4-3500) 1
72 2-1088 Hose Barb, 1/4" Barb x 1/4" Pipe2
73 2-9000 Clamp, Hose #4 2
74 2-10942 Swivel, 1/2" MPT x 3/4" GHF 1
75 4-02110000 Hose, 1/2", Push-On, per ft. 1.3
76 2-1105 Swivel, 1/2" JIC Fem, Push-On 2
77 2-10421 Tee, 1/2" w/1/8" Hole, Street 1
78 2-1062 Elbow, 1/2" JIC x 1/2", 90° 1
79 4-02047720 Hose, 3/8" x 20", 2 Wire
Pressure Loop 1
80 2-0053 Elbow, 1/2" JIC, 3/8", 90° 1
81 2-0051 Nipple, 1/2" JIC, 3/8" Pipe 1
82 2-1060 Elbow, 1/2" JIC x 3/8", 90° 1
83 2-0006 Nipple, 3/8" Hex Steel 1
84 90-1020 Bolt, 3/8" x 2", NC HH 2
85 95-07101216/B Block, Unloader, 3/8" x 3/8",
Brass 1
86 95-07141121 Key, Motor, Shaft (4-35321) 1
▲ Not Shown
EXPLODED VIEW PARTS LIST (CON'T)
PG4-15321, PG4-20321, PG4-25321, PG4-30321, PG4-35321
