14
PG SERIES PRESSURE WASHER OPERATOR’S MANUAL
LANDA PG • REV. 9/02
ITEM PART NO. DESCRIPTION QTY
1 2-10421 Tee, 1/2" w/1/8" Hole, Street 1
2 2-1088 Hose Barb, 1/4" Barb x 1/8" ML
Pipe, 90° 2
3 2-3100544 Valve, E-Z Start 1
4a 4-02100000 Hose, 1/4", Push-On 4ft.
2-01155 Tank Assy, Fuel, 6 Gal. 1
4b 4-02100000 Hose, 1/4", Push-On 1.5ft
5 2-9000 Clamp, Screw, #4 4
6 90-2002 Nut, 3/8", ESNA, NC 2
7 2-2109 Nipple, Coupler, Fuel Line 1
8 10-020PG Label, PG, (Lexan) 1
9 10-2053500 Label, 5-3500 (Lexan) 1
10-2044000 Label, 4-4000 (Lexan) 1
10 10-99060 Label, Plat.
Series Op.Inst/Warn. 1
11 90-10202 Bolt 3/8" x 2-1/2", NC, HH, Tap 8
12 2-0103 Grommet, 1/8", Rubber 4
13 2-0106 Cushion, Pump (Thin) 1
14 2-01172 Belt Guard, PG-Large, Plastic 1
15 2-1050 Plug, 1/2" JIC, Flare 1
16 2-1105 Swivel, 1/2" JIC Fem, Push-on 3
17 2-1108 Push-on, 3/8" Male Pipe 1
2-1101 Adapter, 3/8" X 1/4"
(20 H.P. Honda Only) 1
18 2-810 Key Ring, #1 with Landa 1
19 4-02047720 Hose, 20" x 3/8", 100R2,
Pres Loop 1
20 4-02110000 Hose, 1/2" Push-On /ft. 1.5
21 4-0307 Wheel & Tire Compl, Steel 6" 2
22 4-12805000 Nozzle, SAQMEG, 0005, Red 0°
(5-3500) 1
4-12805015 Nozzle, SAQMEG, 1505,
Yellow 15° (5-3500) 1
4-12805025 Nozzle, SAQMEG, 2505,
Green 25° (5-3500) 1
4-12805040 Nozzle, SAQMEG, 4005,
White 40° (5-3500) 1
4-01404000 Nozzle, 1/4" MEG 0004 SS
(4-4000) 1
4-01404015 Nozzle 1/4" MEG 1504 SS
(4-4000) 1
4-01404025 Nozzle 1/4" MEG 2504 SS
(4-4000) 1
ITEM PART NO. DESCRIPTION QTY
22 4-01404040 Nozzle 1/4" MEG 4004 SS
(4-4000) 1
23 5-0306 Engine, Vanguard 16 HP,
Pull/Start w/Fuel Tank (4-40221,
4-40225, 5-35225, 5-35221 ) 1
5-0317 Engine, Vanguard, 16 HP,E/S,
w/Tank (4-40221E, 5-35221E,
5-35225E, 4-40225E) 1
5-01093 Engine, Honda, 20HP,
Electric Start (PG5-35321E,
PG4-40321E, PG5-35325E,
PG4-40325E) 1
24 95-07101149 Guard, Muffler, Briggs, Vanguard1
25 76-807964 Muffler, Exhaust Skid & PG,
Briggs, Vanguard 1
95-07101214 ▲ Heat Deflector,
Vanguard 16 HP 1
26 95-07101218 Frame, PG, Large 1
95-07101222 Frame, Large (PG5-35321E) 1
27 95-07101135 Bracket, Belt Tension 1
28 2-0053 Elbow, 1/2" JIC, 3/8", 90° 1
29 2-10942 Swivel, 1/2" MP x 3/4" GHF
w/ Strainer 1
2-1902 ▲ Strainer, Inlet Garden Hose 1
30 2-30082 Pump Protector 1/2" PTP 1
31 5-2307 Pump, General, TS-2021
(5-35221E, 5-35321E,
5-35221) 1
5-2320 Pump, General, T-9281,
(PG4-40321E, PG4-40221E,
PG4-40221) 1
5-2271 Pump AR XRCA4.5G30HN
(5-35225, 5-35225E, 5-35325E) 1
5-2272 Pump, AR XRCA4G40HN
(4-40225, 4-40225E, 4-40325E) 1
32 2-0051 Nipple, 1/2" JIC x 1/2" Pipe 1
33 2-1062 Elbow, 1/2" JIC x 1/2", 90° 1
34 2-2007 Nipple, 3/8" x 3/8" NPT ST MAL1
2-20022 ▲ Nipple, 5000 PSI 1
2-0006 ▲ Nipple, 3/8" x 3/8", Pipe
(4-4000) 1
36 5-3208 Unloader, AR, AL607, 7.8 GPM 1
37 95-07101216/B Block, Unloader, 3/8" x 3/8"
Brass 1
38 90-4002 Washer, 3/8", SAE, Flat 6
EXPLODED VIEW PARTS LIST
PG5-35221, PG5-35221E, PG5-35321E, PG4-40221, PG4-40221E, PG4-40321E
