PG SERIES PRESSURE WASHER OPERATOR’S MANUAL
11
LANDA PG • REV. 9/02
ITEM PART NO. DESCRIPTION QTY
1 90-1006 Bolt, 5/16" x 3/4"
NL GR 5 CS ZN 3
2 90-4001 Washer, 5/16", flat, SAE 6
3 10-99060 Label, Platinum Series,
Op. Inst./Warn. 1
4 2-01171 Belt Guard, PG-Small, Plastic 1
5 2-0104 Pad, Hard Rubber 2
6 90-4025 Washer, 3/8" x 1" x 12 GA 2
7 90-10202 Bolt, 3/8" x 2-1/2" NC HH Tap 8
8 90-4007 Washer, 3/8" x 1-1/2", Fender, 1
9 5-511075 Bushing, H x 3/4"
(PG4-15321, PG4-15325) 1
5-511100 Bushing, H x 1"
(All other models) 1
10 5-512024 Bushing, H x 24mm (All models)1
11 5-40403601 Pulley, BK36H
(PG4-15321, PG4-15325) 1
5-40203201 Pulley, 2AK32H (PG4-20325,
PG4-25325, PG4-35325) 1
5-40203001 Pulley, 2AK30H
(PG4-30325, PG4-20321) 1
5-40503201 Pulley, 2BK32H (PG4-35321) 1
5-40203401 Pulley, 2AK34H (PG4-30321) 1
12 5-40407001 Pulley, BK70H
(PG4-15321, PG4-15325) 1
5-40207401 Pulley, 2AK74H (PG4-25321,
PG4-30325, PG4-25325,
PG4-30325,PG4-35325) 1
5-40208401 Pulley, 2AK84H (PG4-30321,
PG4-25321) 1
5-40510001 Pulley, 2BK100H (PG4-4-35321)1
13 5-604035 Belt, BX35 (PG4-15321,
PG4-15325) 2
5-602037 Belt, AX37
(PG4-20325, PG4-20321,
PG4-25325, PG4-25321,
PG4-30325, PG4-35325) 2
5-602038 Belt, AX38 (PG4-30321) 2
5-602035 Belt, AX35
(PG4-20321, PG4-25321) 2
5-604042 Belt, BX42 (PG4-35321) 2
14 95-07101213 Back Plate, Belt Guard,
PG Small 1
95-07101211 Back Plate, Belt Guard, Large
(PG4-35321) 1
15 10-2043000 Label, 4-3000 Lexan 1
ITEM PART NO. DESCRIPTION QTY
15 10-2043500 Label, 4-3500 Lexan 1
10-2041500 Label, 4-1500 Lexan 1
10-2042000 Label, 4-2000 Lexan 1
10-2042500 Label, 4-2500 Lexan 1
16 5-0105 Engine, Honda, 11 HP GX340K1QA
(PG4-30321, PG4-25321,
PG4-25325, PG4-30325) 1
5-010721 Engine, Honda 13 HP
GX390K1QAZ (PG4-35321,
PG4-35325) 1
5-0104 Engine, Honda, 5.5 HP
(PG4-15321, PG4-15325) 1
5-0102 Engine, Honda, 9 HP
(PG4-20321, PG4-20325) 1
17 2-0106 ▲ Cushion, Pump (Thin) .5
18 2-10491 Plug, 1/4" JIC (Honda only) 1
19 2-11062 Swivel, 1/4" JIC Fem, Push-on
(Honda only) 1
20 4-02100000 Hose, 1/4", /ft, Push-on 2.5
21 2-11063 Plug, Push-on, Oil Drain
(Honda only) 1
22 90-2002 Nut, 3/8", ESNA, NC 20
23 90-4002 Washer, 3/8", Flat, SAE 34
24 90-4005 Washer, 5/8", Flat, SAE 4
25 90-2004 Nut, 5/8", Jam, ESNA, NC 2
26 90-1023 Bolt, 3/8" x 5" NC 2
27 95-07101216 Frame, PG/PE Small 1
95-07101218 Frame, Large Belt Drive
(PG4-35321) 1
28 95-07101130 Bumper, 1-1/4" Chrome Grab 1
29 90-10220 Bolt, 3/8" x 3-1/2", Tap 2
30 90-1010 Bolt, 5/16" x 1-3/4", NC HH 4
31 10-020PG Label, PG (Lexan) 1
32 4-0303 Wheel & Tire Assy, 4" Tube 2
4-0307 Wheel & Tire, 6" Steel Rim
(PG4-35321) 1
33 95-07101135 Bracket, Belt Tension 1
34 90-2020 Nut, Cage, 3/8" x 12 GA. 2
35 90-2007 Nut, 3/8", Hex, NC 4
36 95-07101132 Handle, 1-1/4" Chrome 1
37 2-0103 Grommet, Rubber 5
38 4-12804000 Nozzle, SAQCMEG 0004, Red
(PG4-30321, PG4-35321,
PG4-30325, PG4-35325) 1
EXPLODED VIEW PARTS LIST
PG4-15321, PG4-20321, PG4-25321, PG4-30321, PG4-35321
