PG SERIES PRESSURE WASHER OPERATORS MANUAL
17
LANDA PG REV. 9/02
DOWNSTREAM INJECTOR ASSEMBLY
ASSY #3 #4-011183 (EXCEPT 4-4000)
#4-011186 (4-4000)
ITEM PART NO. DESCRIPTION QTY
1 3-1202 Detergent Injector Non Adjust,
#2 (except 4-4000) 1
3-1208 Detergent Injector (No Coupler)
5000 psi, (4-4000) 1
2 2-9000 Clamp, Screw, #4 1
3 4-02080000 Tube, 1/4" x 1/2", Clear Vinyl /ft. 6
ITEM PART NO. DESCRIPTION QTY
4 2-1907 Strainer, 1/4" Hose Barb 1
2-1904 Strainer, 1/4" Hose Barb
(4-4000) 1
5 2-20022 Nipple 3/8" Female 5000 psi
(4-4000) 1
6 2-20021 Coupler, 3/8" Fem. 5000 psi
(4-4000) 1
6
1
5
4-4000
1
2
3
4
