PG SERIES PRESSURE WASHER OPERATOR’S MANUAL
15
LANDA PG • REV. 9/02
ITEM PART NO. DESCRIPTION QTY
39 90-1010 Bolt, 5/16" x 1-3/4", NC HH 4
40 95-07101219 Bracket, Wide Foot 1
41 90-1020 Bolt, 3/8" x 2", NC HH 4
42 90-10220 Bolt, 3/8" x 3-1/2", Tap 2
43 90-2001 Nut, 5/16", ESNA, NC 9
44 90-2002 Nut, 3/8", ESNA, NC 24
45 90-2004 Nut, 5/8", JAM, ESNA, NF 2
46 90-2020 Nut, Cage, 3/8" x 16 Ga 2
47 90-4001 Washer, 5/16", Flat, SAE 16
48 90-4002 Washer, 3/8" SAE, Flat 30
49 95-07101132 Handle, 1-1/4" Chrome 1
50 90-4005 Washer, 5/8", Flat, SAE 4
51 90-1006 Bolt, 5/16" x 3/4" NC GR
5 CS ZN 3
52 95-07101130 Handle, 1-1/4" Chrome Grab 1
53 90-2007 Nut, 3/8", Hex, NC 2
54 92-102 Foot Assy, PG (9-90) 2
55 2-0107 Bellow, Leg (Boot) 2
56 90-1023 Bolt, 3/8" x 5", NC HH Tap 2
57 90-4013 Washer, 3/8" x 1-1/6" x 12 Ga 2
58 90-4015 Washer, 1-1/2" x 3/8" x 12 Ga 2
59 90-5009 Spring, Foot, Compression, New2
60 95-07161114A Tube, Foot Bolt PC 2
61 2-0104 Pad, Hard Rubber 2
62 95-07101113 Holder, Battery, PG
(Elecric Start Only) 1
63 95-07101114 Clamp, Battery, PG
(Electric Start Only) 1
64 95-07101211 Back Plate, Belt Guard, PG, Lg. 1
65 90-4006 Washer, 5/16" x 1-1/4", Fender,
SAE 2
66 5-511100 Bushing, H x 1" (PG4-4000,
PG5-3500) 1
67 5-40504501 Pulley, 2BK45H (PG4-40321E,
PG4-40221, PG4-40221E,
PG4-40225, PG4-40225E,
PG5-35225, PG5-35225E,
PG5-35325E, PG4-40325E) 1
5-40503201 Pulley, 2 BK32 H (PG5-35221,
PG5-35221E, PG5-35321E) 1
68 5-40508001 Pulley, 2BK80H (PG4-40221,
PG4-40221E, PG5-35221,
PG5-35221E, PG5-35321E,
PG4-40321E, PG5-35225,
PG5-35225E, PG5-35325E) 1
ITEM PART NO. DESCRIPTION QTY
68 5-40507001 Pulley, 2BK70H (PG4-40225,
PG4-40225E, PG4-40325E) 1
69 5-604040 Belt, BX40 (PG5-35221,
PG5-35321E, PG4-40221E,
PG5-35221E, PG4-40221) 2
5-604041 Belt, BX41 (PG4-40321E) 2
5-604037 Belt, BX37 (PG5-35225,
PG5-35225E) 2
5-604038 Belt, BX38 (PG5-35325E,
PG4-40225, PG4-40225E,
PG4-40325E) 2
70 5-512024 Bushing, H x 24 mm 1
71 2-0006 Nipple, 3/8" Hex 1
72 2-1060 Elbow, 1/2" JIC x 3/8" 1
73 90-1016 Bolt, 3/8" x 1", NC HH 4
74 10-02029 Label, Danger Cool Engine 1
75 10-020251 ▲ Label, “Hot” Muffler Warning 1
76 90-1021 Bolt, 3/8" x 2-1/2" GR 5 ZN 2
77 2-9000 Clamp, Screw
(Honda 4-40321E) 5
78 10-99081 Label, Prop. 65 Warning 1
79 4-16540 Nozzle, Brass Soap (5-3500) 1
4-0146540S Nozzle only, 1/4" U-6540,
Brass (4-4000) 1
80 2-20024 Nipple 1/4" Female 5000 psi
(4-4000) 5
81 2-2108 Coupler, Fuel Line, Quick
(Honda 4-30321E) 1
82 4-02100000 Hose, 1/4", Push-On, Fuel Line
Per Ft. 2.5
83 2-01152 Fuel Tank, 6 Gal. 1
2-01155 Tank Assy, Fuel, 6 Gal. (includes
4a, 77, 81, 83 & 84) 1
84 2-1085 Hose Barb, 1/4" Barb x 1/8" Pipe
(Honda 4-40321E) 3
85 2-1084 Hose Barb 1/4" Barb x 1/8" ML
(Fuel Tank Assy PG4-40321E) 1
86 2-1084 Hose Barb, 1/4" Barb x 1/8" ML
(PG4-40321E) 1
87 95-07141121 Key, Motor Shaft (4-40321E,
5-35221E, 4-40221) 1
▲ Not Shown
EXPLODED VIEW PARTS LIST (CON'T)
PG5-35221, PG5-35221E, PG5-35321E, PG4-40221, PG4-40221E, PG4-40321E
