Quick Start
WiBox2100E User Guide 25
WebPort
Displays the WiBox’s port for Web-Manager configuration.
Maximum Baud Rate
Supported
Displays the WiBox’s maximum baud rate. Note: The WiBox
may not currently be running at this rate.
Firmware Upgradeable
Displays True, indicating the WiBox’s firmware is upgradeable
as newer version become available.
IP Address Displays the WiBox’s current IP address. To change the IP
address, click the Assign IP Address button.
Number of COB
partitions supported
Displays the number of COB partitions supported (between 19
and 59).
Supports DynamicIP Indicates whether the current IP address was set using static
or DHCP.
Subnet Mask Displays the WiBox’s current subnet mask. To change the
subnet mask, click the Assign IP Address button.
Gateway Displays the WiBox’s current gateway. To change the
gateway, click the Assign IP Address button.
Number of Ports
Displays the number of ports on the WiBox.
TCP Keepalive valid
range
Displays 45, the WiBox’s TCP keepalive range.
Supports Configurable
Pins
False
Supports Email Triggers False
Supports AES Data
Stream
Displays True if the WiBox unit supports AES encryption.
Supports 485 Displays True if the WiBox supports the RS-485 protocol.
Supports 920K Baud
Rate
Displays True if the WiBox supports baud rates up to 920K.
Supports Wired Ethernet
WBX2100E supports wired Ethernet.
