Web-M
anager Conf
iguration
WiBox2100E User Guide
44
Updating Settings
1.
If you have not already done so, click the
Apply
Settings
button from the main
menu to save and apply the configuration cha
nges.
Applying Defaults
Click the
Apply
Defaults
button to reset the unit’s settings to the factory defaults,
except for the network IP address, gat
eway, netmask, and WLAN settings. For
a
complete list of the default settings, see
Default Settings
on page 72.
43
45
