Lantronix Ethernet - Table 7-5. Connect Mode Options

Setup Mode: Channel Configuration
WiBox2100E User Guide 53
Note: All bit positions in the table that are blank represent “don’t care” bits for
that particular option; they can be set to either a 0 or 1 value.
Table 7-5. Connect Mode Options
Connect Mode Option 7 6 5 4 3 2 1 0
a) Incoming Connection
Never accept incoming 0 0 0
Accept with DTR Active 0 1 0
Always Accept 1 1 0
b) Response
Nothing (quiet) 0
Character response (C=connect,
D=disconnect, N=unreachable)
1
c) Active Startup
No active startup 0 0 0 0
With any character 0 0 0 1
With DTR Active 0 0 1 0
With a specific start character 0 0 1 1
Manual connection 0 1 0 0
Autostart 0 1 0 1
Hostlist 0 0 1 0
d) Datagram Type
Directed UDP 1 1 0 0
e) Modem Mode
No Echo 0 0 1 1
Data Echo & Modem Response
(Numeric)
0 1 1 1 1
Data Echo & Modem Response
(Verbose)
0 1 1 1 0
Modem Response Only (Numeric) 0 0 1 1 1 1
Modem Response Only (Verbose) 0 0 1 1 1 0
