Larsen & Brusgaard ALTITRACK - Description; Analog Face

11
2 - Description
2.1 Analog Face
1. Right Front Button
• PowerON
• Enable/Disablebacklight
• PowerOFF
2. Left Front Button
• PowerON
• PerformACCESS
• AdjustaltitudeiftheDZelevationdiffers
from that of the airport of take-off
• EnableIrDa
3. “ACCESS” indicator
4. “LOW BAT” indicator
5. Data Port
1
2
3
4
5
Fig.1–Analogface
