Spartan 821/721 Manual Instrument Hardware Specifications A-3
A.1.2 Hardware Physical Specifications
Sound Level Meter Physical Specifications
FIGURE A-1 Meter Dimensions
Dimensions:
260.4 x 82.6 x 32.3mm (10.25 x 3.25 x 1.27 inches) including microphone and
preamplifier
203.2 x 82.6 x 32.3 mm (8.0 x 3.25 x 1.27 inches) instrument body only
Weight:
382.5 g (13.5 oz) including batteries, preamplifier, and microphone
342 g (12.1 oz) instrument body only
