Spartan 821/721 Manual Hardware Overview 2
1.1 Hardware Overview
FIGURE 1-1 Main Body: Front and Back
Preamplifier release
LED Status Light Indicator
See
2.2.2 LED Status Light
Power
button
SD Card access door
CAUTION Power off the meter
before opening the door.
See
4.2 Managing SD Card
Storage
Wireless
Charge Coils
(Internal)
Bluetooth
Meter mount
