12. Attach the trapeze rings to hull mounted
shock cords by feeding the elastic loop
through the ring at the bottom of the
pulley. (Note: Trapeze kit is an option on
the standard rig but is included in the XD
rig)
13. Place the Loop of elastic shock cord over the
metal trapeze ring and pull tight.
14. Tip - Best seaman like practise would be to tie
two double half hitch stopper knots in the adjuster
line (a hand width apart).
Boom and Gnav
1. Unpack the boom and
Gnav tackle.
2. Attach the boom to the mast
using the drop nose pin.
(Articulating toggle at the
bottom)
3. Tie the Gnav control line from
the boom to the double block a
becket at the base of the mast
the boat.
nd
in
(Tip - Best seaman like practise
would be to use a bowline)
12
