Lastec Mower 3300 - Steering Control Arms

Initial Set-Up
Steering Control Arms.
Initial Set-Up Lastec//030910 3-15
3
3.16 Steering Control Arms.
Check that both steering control arms are properly linked,
free of debris, and operating freely. Swing the arms toward
the operator seat, removing them from the neutral lock
position. Slowly push both arms all the way forward, then all
the way back. They should both move smoothly and easily,
with no sticking, obstruction, or uneven tension. They
should also slowly return back to neutral position, which is
straight up and down and centered with the neutral position
lock (notch in the frame)
Be sure to return and lock both control arms into neutral
position.
The control arms can be adjusted for operator comfort by
repositioning the control arms on the control assembly.
