Initial Set-Up
Tires and Wheels
3
3-18 Lastec//030910 Initial Set-Up
6. Repeat the measuring technique on deck 2 and 4. The adjust-
ment rods on both the rocker and the rear wheels can be.made
in the same manner as the center deck adjustment.
7. If greater adjustment are need on deck 2 and 4, additional
adjustment can be made on the turnbuckle leading from the
rocker to the deck. Adjust the jam nut on the turnbuckle as you
would on the adjustment arms. Be sure to retighten the jam
nuts on the turnbuckle after leveling the deck.
8. Level the outer decks, 1 and 5, last. If use the jam nuts on the
adjustment rod to make minor adjustments.
3.19 Tires and Wheels
Check the air pressure in the rear drive tires. Maintain air pressure at 18 psi, or as needed
to maintain level deck cutting.
Check the air pressure in the front tires. Maintain air pressure at 12 psi, or as needed to
maintain level deck cutting
Verify proper function of all mower deck wheels. The wheels should turn freely without
excessive side-to-side motion, and be free of debris. Clean, adjust, replace, and grease
as necessary.
Check that each wheel swivels freely in the shaft pivot collar, and the bearings are in
good condition. If any wheel does not swivel freely, clean and grease the shaft collar
assembly. Replace the bearings if necessary.
