Lastec Mower 3300 Specifications
5
5-6 Lastec//030910 Maintenance
5.13 Lastec Mower 3300 Specifications
PART #
Mowers Mower Deck Configuration (5) 21” Articulating Decks
Width 100”
Blades (3) 21” High-Lift P128
(3) 21” Low-Lift P246
(3) 21” Mulching Blades P322
Blade Tip Speed Max 16,600
Mower Deck Height Range 1” to 4-1/2”
Paint Red, 12 oz spray P299
Black, 12 oz spray L07467
Gross Weight 2142 pounds (971.6kg)
Front Wheel Assemblies 13” x 6.5 x 6 Reliance 045986
Drive Wheel Assembly 12 x 12-12 Tire w Offset Rim 026439
Rim alone 12 x 8-1/2 8 Spoke 4-1/2 BC 026440
Tire alone 26 x 12-12 059928
Gage Wheels 9 x 3.5 Solid 056600
Clutch Warner C Cross Section 058500
Main Drive Belt Belt, Mule Drive C136 058804
Deck Drive Belts -- Center Belt, B-128 Deck Drive 049855
Wing Decks Belt, Insta-Power 85830 041630
Maximum Forward Speed Infinitely variable up to 8.5 mph (13.7kh)
Noise Levels 105 dB or lower
Transmission Hydraulic Pump, Left Pump, PW Series Left 049235
Hydraulic Pump, Right Pump, Hydrogear 21cc w/Aux. w/Return 058505
Hydraulic Motors Left
1
1
Left and Right hydraulic wheel motors are the same unit -- direction is controlled through hose attachements. See Hydraulic System
Diagram following this chart.
Motor, Hydraulic MB29 018741
Hydraulic Motors Right Motor, Hydraulic MB29 018741
Hydraulic Fluid
2
2
Lastec hydraulic fluid is equivalent to Shell Oil TTF-SB and Mobil One Synthetic 15w50
Lastec Hydro Oil 040642
Hydraulic Fluid Filter 25 Micron, & GPM Full-flow, 3/8” NPT P620
Hydraulic Fluid Capacity 5 quarts
Hydraulic Pump Drive Belt Belt, AX-62
