23. WALL MOUNTING
44
45
Caution: The supplied screws are intended for use on a thick wooden wall or wooden
column. Do not use any other materials. The Time Recorder may come off if used on
other materials.
1
Install the supplied wall-mount screws
into a wall by using the template.
Be sure to keep about (1/4") 6mm of
the screw head away from the wall.
2
Unlock the key and remove the cover.
And then hang it on the wall.
3
Replace cover and lock.
WALL
WALL
