Lattice Semiconductor CrossLink User Manual

CrossLink Programming and Configuration Usage Guide
Technical Note
© 2015-2017 Lattice Semiconductor Corp. All Lattice trademarks, registered trademarks, patents, and disclaimers are as listed at www.latticesemi.com/legal. All other brand or product names are
trademarks or registered trademarks of their respective holders. The specifications and information herein are subject to change without notice.
FPGA-TN-02014-1.2 29
Date
Version
Change Summary
February 2017
1.1
 Updated the Configuration Ports Default Behavior and Arbitration section with
default behavior
 Updated the Configuration section with two cases
 Added Note 2 to Table 4.4. Default State in Diamond for each Port
 Changed CCLK to “MCK or SPI_SCK”, MCK to CSN, and general purpose I/O to
SPI_SS in the Master and Slave SPI Configuration Port Pins section
 Changed MCLK to MCK in Master SPI Configuration Mode section
 Added reference to the Programming Tools User Guide
August 2016
1.0
Updated document numbers, the previous document number was TN1303.
May 2016
1.0
First preliminary release.
