ID Function Unit, resolu-
tion
Command
33 Set temperature T
set
in Safe Mode (Safe set point in case of communication
interruption).
[°C] IN_SP_07
158 Actuating signal of master controller in case of external control [°C] IN_PV_11
Table 11: Pump
ID Function Unit Command
6 Outflow pressure / pump pressure, relative to the atmosphere
(only for Integral XT)
[bar] IN_PV_02
12 Through-flow of the pump
(MID flow controller must be connected)
[l/min] IN_PV_07
18 Pump power stage
(only for Integral XT)
[–] IN_SP_01
31 Outflow pressure set point / pump pressure (for pressure control settings)
(only for Integral XT)
[bar] IN_SP_06
37 Through-flow control set point [l/min] IN_SP_09
71 Status of through-flow control: 0 = o / 1 = on [–] IN_MODE_05
154 Outflow pressure of flow controller, relative to the atmosphere
(MID flow controller must be connected)
[bar] IN_PV_09
156 Pressure limitation set point with active through-flow control
(MID flow controller must be connected)
[bar] IN_SP_10
157 Overpressure turn o point with active through-flow control
(MID flow controller must be connected)
[bar] IN_SP_11
160 Valve position of the flow controller
(MID flow controller must be connected)
[%] IN_PV_12
164 Pressure measurement value source [--] IN_MODE_07
Table 12: Fill level
ID Function Unit Command
9 Heat transfer liquid level (fill level) [–] IN_PV_05
V6Integral Process Thermostats and High-Temperature Thermostats54 / 198
