LAUNCH X-431IV English User’s Manual
6
No. Name Descriptions Photos
1
CF 卡
To store diagnostic programs and data
2 CF card
reader writer
To read or write data on the CF card
3 Diagnostic
connector
Dozens of connectors are equipped for
various vehicles. Here shows a typical one.
4 Cigarette
lighter cable
To get power from the vehicle cigarette lighter
5 Main cable To connect the diagnostic connector and
X-431IV main unt
6 Stylus Click or write on the screen with the stylus
7 Thermal paper For printing
2.3 Technical Specifications
Operating System: LINUX
Memory: 16M
CF Card: 1G
Main Unit I/O: Universal Serial Bus /Standard Parallel port
Main Unit Voltage: DC12V
Main Unit Power: approximately 9W
Printer: Thermal mini-printer
Display Screen: 240X320 LCD with touch screen and backlit
Ambient temperature: 0-50℃
Relative Humidity: <90%
Dimension: 198mm×316mm×55.5mm
