CReader Series English User’s Manual
8
3. Product Descriptions
3.1 Outline of CReader 6011/7001/7001F/8001/8011/8021/9081
Figure 3-1 CReader 6011/7001/7001F/8001/8011/8021/9081 Front View
Note: CReader 6011/7001/7001F/8001/8011/8021/9081 feature same appearance.
No.
Name Descriptions
A
DB-15 connector
To connect the tool to the vehicle's DLC (Data Link
Connector) via the diagnostic cable.
B
Diagnostic cable
1 LCD Indicates test results.
2 DTC(F1) To read the DTCs.
3 (ESC)
Exit the current program or return to the previous
screen.
4

/

Move cursor up and down for selection.
